E40XMHL
29.4 kW (40 ps)
HKD $23,950



Performance
Max.prop Shaft Output29.4 kW (40 ps)
Full Throttle Operating Range4500 – 5500 r/min
Idling Speed950 – 1050 r/min
Fuel Consumption20.0 L/h @5500 r/min

Engine
Engine TypeIn-line 2
Displacement703 cm³
Bore X Stroke80.0× 70.0 mm
Compression Ratio6.0 :1
Starting EnrichmentManual choke
Fuel Induction System1 carburetor
Lubrication SystemPre-mixed fuel and oil
Ignition SystemCDI
Ignition TimingATDC 2.0 – BTDC 23.0 deg.
Spark PlugB7HS
Alternator80 W (optional) W, WH, WT: 6 A
Cooling SystemRaw-water, thermostatically controlled
Exhaust SystemThrough propeller boss

Bracket / Drive
Trim7 positions
Shallow Water Drive2 positions
Steering Angle45 deg. each direction
Gear ShiftF-N-R
Gear Ratio2.00 (26/13)
Gear Oil Capacity0.430 L
Propeller FittingSpline
Propeller RotationClockwise
Engine Transom Height550 mm (21.7 in),
